Compact Design Stainless Steel Built-in Membrane Housing OEM Service Available

Our Stainless Steel Built-in Membrane Housing redefines filtration system design by integrating the membrane vessel directly into your processing skid or equipment framework. Engineered for maximum space efficiency and performance optimization, this innovative housing solution eliminates external piping complexities while delivering superior membrane protection and system reliability. Perfect for OEM applications, modular water treatment systems, and space-constrained installations where traditional standalone housings are impractical.

Model:
Customized
Brand:
Keyuan

Availability:

Quantity:



Inquire Add to Basket

Product Description

Parameter Overview:

Side inlet, 8-inch membrane housing built-in type

Work pressure: 300PSI/600PSI

Maximum working temperature: 90 ℃

Shell material: Stainless steel 304/316L

End cap material: stainless steel 304/316L

O-ring material: EPDM, NSF grade

Surface treatment: mechanical polishing (320 mesh, Ra<0.6)

Model: Equipped with 8040 standard membrane housing, can hold 1-6 pieces

Model	L (mm)	L1 (mm)	D (mm)	A In	B Out
KY-MKN-8040	1359	1119	∅203	11/2"-3"	1"
KY-MKN-8080	2375	2135	∅203	11/2"-3"	1"
KY-MKN-80120	3391	3151	∅203	11/2"-3"	1"
KY-MKN-80160	4407	4167	∅203	11/2"-3"	1"
KY-MKN-80200	5423	5183	∅203	11/2"-3"	1"
KY-MKN-80240	6439	6199	∅203	11/2"-3"	1"

Key System Advantages
1. Unmatched Space Efficiency
Zero External Footprint: Housing occupies no additional floor space beyond the equipment frame itself
Vertical/Horizontal Flexibility: Can be oriented to utilize otherwise wasted spaces within equipment envelopes
Modular Stackability: Multiple housings can be vertically or horizontally stacked within shared structural elements

2. Enhanced System Performance
Minimized Pressure Loss: Elimination of external fittings and piping reduces system pressure drop by 25-40%
Improved Flow Distribution: Precision-machined inlet/outlet manifolds ensure equal flow to all membrane elements
Thermal Efficiency: Integrated design improves heat retention in hot water systems and reduces thermal cycling stress

3. Superior Reliability & Maintenance
Reduced Failure Points: 60% fewer connections and joints compared to conventional piped systems
Quick Membrane Access: Top or side-loading designs with quick-release covers for easy maintenance
Corrosion Protection: Continuous 316L material throughout wetted surfaces eliminates galvanic corrosion risks

Industry Applications
Packaged Water Treatment Systems
Containerized desalination units
Mobile pure water systems
Emergency water supply units
OEM Equipment Integration
Pharmaceutical water purification skids
Food & beverage process water systems
Laboratory pure water generators
Industrial Process Integration
Chemical processing equipment
Power generation auxiliary systems
Manufacturing process water integration
Special Applications
Marine and offshore water systems
Military field water purification

Remote mining and exploration camps

Why Choose Our Built-in Membrane Housing?
Maximum Space Utilization: Transform unused spaces into functional filtration capacity
System Optimization: Engineered as part of an integrated system, not an add-on component
Reduced Installation Time: Pre-integrated design cuts installation time by 50-70%
Enhanced Reliability: Fewer connections and joints mean fewer potential failure points
Lifecycle Cost Savings: Lower installation costs, reduced maintenance, and improved energy efficiency
